ABB RET670 Installation And Commissioning Manual

PosNo Description Quantity Type
1 Bushing 4 -
2 Screw 8 M4x10
3 Screw 4 M6x12 or
corresponding
4 Mounting bar 2 -
5 Screw 6 M5x8
6 Side plate 2 -
Procedure
1.
Mount the mounting bars onto the wall (4).
See section
"Wall mounting dimensions" for mounting dimensions.
Depending on the wall different preparations may be needed like drilling and
inserting plastic or expander plugs (concrete/plasterboard walls) or threading
(metal sheet wall).
2.
Make all electrical connections to the IED terminal.
It is much easier to do this without the unit in place.
3. Mount the side plates to the IED.
4. Mount the IED to the mounting bars.
5.3.4.3 How to reach the rear side of the IED
The IED can be equipped with a rear protection cover, which is recommended to
use with this type of mounting. See figure
14.
To reach the rear side of the IED, a free space of 80 mmis required on the unhinged
side.
1MRK 504 088-UEN C Section 5
Installing the IED
37
Installation and commissioning manual

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
