1
2
3
4
5
6
7
8
en05000056.eps
IEC05000056-CALLOUT V1 EN
Figure 43: Medium size graphic HMI
1 Status indication LEDs
2 LCD
3 Indication LEDs
4 Label
5 Local/Remote LEDs
6 RJ45 port
7 Communication indication LED
8 Keypad
1MRK 504 088-UEN C Section 7
Energizing the IED
79
Installation and commissioning manual
