ABB TRIO-50.0-TL-OUTD

- 103 -
000542AG
7 - Operation
• Alarm with reset at the end of the alarm signalling process "Alarm"
The relay is activated (status: switched) whenever an error (code Exxx)
or warnings related to grid parameters out of range (Warning – codes
W003, W004, W005, W006, W007) are present on the inverter. The alarm
returns to its resting position when the alarm signal ends, i.e. before the
inverter checks the grid parameters after the alarm state. This is because
grid control state is not an alarm state but a state of normal operation.
Alarms for which the relay is activated
E001 E002 E003 E004 E005 E006
E007 E009 E010 E011 E012 E013
E014 E015 E016 E017 E018 E019
E020 E021 E022 E023 E024 E025
E026 E027 E028 E029 E030 E031
E032 E033 E034 E035 E036 E037
E046 E050 E053 E054 E055 E056
E057 E058 E077 E078 E081 E084
E089 W003 W004 W005 W006 W007
In the presence of W003, W004, W005, W006, W007 signalling, the alarm contact switches
to then reset itself at the end of the alarm signal. This means that during the absence of grid
voltage (display message “Missing Grid”) the alarm contact remains in its resting position.
• Congurable alarm with reset at the end of the alarm signalling
process "Alarm (Conf.)"
The relay is activated (status: switched) whenever an error (code Exxx)
or a warning (code Wxxx) is present from those selected from the list in
the dedicated submenu Alarm Cong. The contact returns to its resting
position when the alarm signal ends, i.e. before the inverter checks the
grid after the alarm state. This is because grid control state is not an
alarm state but a state of normal operation.
Selectable alarms for which the relay is activated
E001 E002 E003 E004 E005 E006
E007 E009 E010 E011 E012 E013
E014 E015 E016 E017 E018 E019
E020 E021 E022 E023 E024 E025
E026 E027 E028 E029 E030 E031
E032 E033 E034 E035 E036 E037
E046 E050 E053 E054 E055 E056
E057 E058 E077 E078 E081 E084
E089 W001 W002 W003 W004 W005
W006 W007 W009 W011 W015 W046
W047 W048 W051 W058 W059
INVERTER IN FUNZIONE
- PRODUZIONE -
PRESENZA DI
UN ERRORE
SEGNALAZIONE ERRORE
t=15s
CONNESSIONE ALLA RETE
ERRORE
ANCORA PRESENTE?
Si No
N.C.
N.O.
N.C.
N.O.
N.C.
N.O.
Stato relè: commutato
Stato relè: a riposo
Stato relè: a riposo
INVERTER IN FUNZIONE
- PRODUZIONE -
PRESENZA DI UN
ERRORE/WARNING
SELEZIONATO
Si No
N.C.
N.O.
N.C.
N.O.
N.C.
N.O.
SEGNALAZIONE ERRORE
t=15s
CONNESSIONE ALLA RETE
ERRORE/WARNING
ANCORA PRESENTE?
Stato relè: commutato
Stato relè: a riposo
Stato relè: a riposo
