ABB TRIO-50.0-TL-OUTD

- 22 -
000521CG
2 - Characteristics
Tightening torques
To maintain the IP65 protection of the system and for optimal installation,
the following tightening torques must be used:
DC Wiring box
02
Service cable gland
34
PG 21
5.0 Nm
Service cable gland
35
PG 16
2.7 Nm
DC cable glands
11
M32 (only Standard / -S versions)
8.0 Nm
Front cover
08
2.4 Nm
DC input terminal block
13
95 mm
2
(Standard / -S version)
20 Nm
Mounting screws for earth connection brackets
32
11Nm
Power module
03
Mounting screws for earth connection brackets
32
11Nm
AC Wiring box
05
Single AC cable gland
16
PG 42
10 Nm
Single AC cable glands
30
M32 (not supplied)
8.0 Nm
Front cover
08
2.4 Nm
AC output terminal block
17
95 mm
2
(Standard version)
20 Nm
AC disconnect switch terminal block
36
70 mm
2
(-S / -SX version)
6 Nm
Mounting screws for earth connection brackets
32
11Nm
Cable gland clamping range
DC Wiring box
02
Service cable gland
34
PG 21
13...18mm
Service cable gland
35
PG 16
10...14mm
DC cable glands
11
M32 (Standard / -S versions)
13...21mm
AC Wiring box
05
Single AC cable gland
16
PG 42
28...38mm
Single AC cable glands
30
M32 (not supplied)
13...21mm
