ABB TRIO-50.0-TL-OUTD

- 21 -
000521CG
2 - Characteristics
Table: Technical Data TRIO-50.0-TL-OUTD
Operating performance
Maximum Efciency (ηmax) 98.30%
Weighted Efciency (EURO/CEC) 98.0% / -
Communication
Remote Monitoring
VSN300 Wi Logger Card (opt.),
VSN700 Data Logger (opt.)
Wireless local monitoring VSN300 Wi Logger Card (opt.)
User Interface LEDs
Available ports 2 (RS485)
Environmental
Ambient temperature range -25...+60°C /-13...140°F with derating over 50°C / 122°F
Storage temperature -40°C...+85°C / -40°F...185°F
Relative Humidity 4…100 % with condensation
Typical noise emission pressure 75 dB(A) @ 1 m
Maximum operating altitude without derating 2000 m / 6560 ft
Environmental pollution degree
classication for external environments
3
Environmental class Outdoor
Physical
Environmental Protection Rating IP 65 (IP54 for the cooling section)
Cooling System Forced air
Dimensions (H x W x D) 725 mm x 1491 mm x 315 mm / 28.5” x 58.7” x 12.4”
Weight
95 kg total
66 kg power module
15 kg for AC wiring box (full optional)
14 kg for DC wiring box (full optional)
Assembly System Wall bracket or horizontal support
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Insulation Level Without transformer (TL)
CE Marking CE
Safety and EMC Standards
IEC/EN 62109-1, IEC/EN 62109-2, EN 61000-6-2,
EN 61000-6-3, EN 61000-3-11, EN 61000-3-12
Grid standard (check the availability with
your sales channel)
CEI 0-21, CEI 0-16, DIN V VDE V 0126-1-1,
VDE-AR-N 4105, G59/3, EN 50438 (not for all national appendices),
RD 1699, RD 413, RD 661, P.O. 12.3, AS 4777, BDEW, NRS-097-2-
1, MEA, PEA, IEC 61727,
IEC 60068, IEC 61683, VFR-2014, IEC 62116
Accessories
TRIO-50.0/60.0-GROUNDING KIT Allows to connect the negative input pole to ground
TRIO-AC-WIRING-KIT
Allows to connect the AC output cables, copper or aluminum, with
cross section up to 150mm
2
1. The output voltage range may vary according to the grid standard of the country of installation
2. The output frequency range may vary according to the grid standard of the country of installation
3. In the event of a fault, limited by the external protection envisaged on the AC circuit
4. Please refer to the document “String inverters – Product manual appendix” available at www.abb.com/solarinverters for informa-
tion on the quick-t connector brand and model used in the inverter.
5. The maximum accepted current for each group of inputs (3 or 4 strings based on the DC wiring box model) is 54A
Note. Features not specically mentioned in this data sheet are not included in the product
