Setting Parameters
Changing certain parameters may prevent disconnection from the grid if the new values
exceed those given in the standards of the country of installation. If these parameters are
changed to values outside the standard range, an interface protection must be installed
external to the inverter in accordance with the requirements of the country of installation.
These parameters can only be displayed with the Aurora manager Lite
interface SW.
The table below shows the parameters that can be changed and the
range of values that may be set for each:
Parameter Description Setting range
Set U>> Grid over-voltage (OV) threshold (extended range) Unom … Unom x 1.3
Set U<<
Grid under-voltage (UV) threshold (extended range) 10V … Unom
Set F>> Grid over-frequency (OF) threshold (extended range) Fnom … Fnom + 5Hz
Set F<< Grid under-frequency (UF) threshold (extended range) Fnom - 5Hz … Fnom
Set U> Grid over-voltage (OV) threshold (restricted range) Unom … Unom x 1.3
Set U> (10Min) Over-voltage (OV) threshold (average grid voltage value) Unom … Unom x 1.3
Set U< Grid under-voltage (UV) threshold (restricted range) 10V … Unom
Set F> Grid over-frequency (OF) threshold (restricted range) Fnom … Fnom + 5Hz
Set F< Grid under-frequency (UF) threshold (restricted range) Fnom - 5Hz … Fnom
Set Uconn> Max. permissible voltage during checks prior to grid connection Unom … Unom x 1.3
Set Uconn< Min. permissible voltage during checks prior to grid connection 10V … Unom
Set Fconn> Max. permissible frequency during checks prior to grid connection Fnom … Fnom + 5Hz
Set Fconn< Min. permissible frequency during checks prior to grid connection Fnom - 5Hz … Fnom
Set Time U>> Over-voltage U>> protection tripping time 0 … 327670mS
Set Time U<< Under-voltage U<< protection tripping time 0 … 327670mS
Set Time F>> Over-frequency F>> protection tripping time 0 … 327670mS
Set Time F<< Under-frequency F<< protection tripping time 0 … 327670mS
Set Time U> Over-voltage U> protection tripping time 0 … 327670mS
Set Time U< Under-voltage U< protection tripping time 0 … 327670mS
Set Time F> Over-frequency F> protection tripping time 0 … 327670mS
Set Time F<
Under-frequency F< protection tripping time 0 … 327670mS
Set time conn 1
Grid check time prior to connection 0 … 65535mS
Set time conn 2 Grid check time prior to connection after a grid fault 0 … 65535mS
Disable U>> Disables the U>> protection threshold Enabled/Disabled
Disable U<< Disables the U<< protection threshold Enabled/Disabled
Disable F>> Disables the F>> protection threshold Enabled/Disabled
Disable F<< Disables the F<< protection threshold Enabled/Disabled
Disable U> Disables the U> protection threshold Enabled/Disabled
Disable U> (10Min) Disables the U> (10Min) protection threshold Enabled/Disabled
Disable U< Disables the U< protection threshold Enabled/Disabled
Disable F> Disables the F> protection threshold Enabled/Disabled
Disable F< Disables the F< protection threshold Enabled/Disabled
U> (10Min) Der.
Enables power derating mode due to high average grid voltage
readings
Enabled/Disabled
Slow Ramp Enables gradual ramping up of power after the grid connection. Enabled/Disabled
OF Derating
Selects the power derating mode in the event of grid over-frequency. 0 Derating disabled
1 BDEW derating
2 VDE-AR-N derating
3 CEI derating
Reset Country S.
Unlocks the grid standard selection (resets the 24 hours available for
changing the grid standard)
Accept boards
Used to associate a new board with the inverter (in the event of
replacement)
