ABB TRIO-50.0-TL-OUTD

- 20 -
000521CG
2 - Characteristics
Characteristics and technical data
Table: Technical Data TRIO-50.0-TL-OUTD
Input
Absolute Maximum Input Voltage
(Vmax,abs)
1000 V
Input start-up voltage (Vstart) 360…500 V (default 420)
Input operating interval (Vdcmin...Vdcmax) 0.7xVstart ...950 V (min 300 V)
Rated Input Voltage (Vdcr) 610 Vdc
Input Nominal Power(Pdcr) 51200 W
Number of Independent MPPT 1
MPPT DC Voltage Range (VMPPTmin ...
VMPPTmax) to Pacr
480-800 Vdc
Maximum DC Input Current (Idcmax) 108 A
Maximum Return current (AC side vs DC
side)
Negligible in normal operating conditions
(3)
Maximum short circuit current (Iscmax) 160 A
Number of DC Connection Pairs in Input 12 or 16 (-SX version) ; 12 (-SY version)
Maximum current for each quick t connec-
tor (-SX / -SY version)
13.5A for 16 DC inputs wiring box version
(5)
Type of Input DC Connectors
Screw terminal block max. cross-section 95mm
2
(Standard and -S version)
PV quick t connector
(4)
(-SX and -SY version)
Type of photovoltaic panels that can be con-
nected at input according to IEC 61730
Class A
Input protection
Reverse Polarity Protection Yes, from current limited source
Input Overvoltage protection - Varistors Yes, 2
Overvoltage protection - Modular surge arrester
-SX: Classe II
-SY: Classe I+II
Insulation Check Complying with the local standard
Characteristics of DC disconnect switch
(versions with DC disconnect switch)
200 A / 1000 V
String fuses (-SX/-SY versions) 15A (gPV / 1000Vdc / Max. installable size 20A)
Output
AC Connection to the grid
3Ø grounded WYE system only,
3W + GND (no N connection) or 4W + GND (with N connection)
Nominal AC Output Power (Pacr @cosφ=1) 50000 W
Maximum AC Output Power (Pacmax @cosφ=1) 50000 W
Maximum apparent Output power (Smax) 50000 VA
Rated AC Output Voltage (Vacr) 400 V
Output voltage range (Vacmin...Vacmin) 320...480 V
(1)
Maximum output current (Iacmax) 77 A
Contribution to short-circuit current 92 A
Rated Output Frequency (fr) 50 Hz / 60 Hz
Output Frequency Range (fmin...fmax) 47...53 Hz / 57…63 Hz
(2)
Nominal power factor and setting interval > 0.995, 0...1 inductive/capacitive with maximum Smax
Total harmonic distortion of current <3%
AC Connections Type
Screw terminal block - single AC cable gland PG42 (default congura-
tion) or 5 single AC cable glands (not supplied)
Output protection
Anti-islanding Protection
Complying with the local standard (active frequency drift combined
with RoCoF techniques)
Maximum external AC overcurrent protection 100 A
Output overvoltage protection - Varistors Yes, 4
Output overvoltage protection - Modular
surge arrester (-SX version)
4, Classe II
