4 - Lifting and transport
List of components supplied
Supplied with the inverter are all the components required to correctly
install and connect the inverter
Components available for all DC wiring box models Qty
Connector for connection of the congurable relay 2
Connector for connecting the communication and con-
trol signals
2
Two-hole gasket for signal cable glands
34
PG 21 + cap
2
Two-hole gasket for signal cable glands
35
PG 16 + cap
1
M6 nut for securing the ground terminal onto the AC wi-
ring box
1
M6 toothed washer for securing the ground terminal onto
the AC wiring box
2
In addition to what is explained in this guide, the safety and installation information provided in the installation manual must be read and followed.
The technical documentation and the interface and management software for the product are available at the website.
XXXXXXXXXXXXXXXXXXX
XXXXXXXXXXXXXXXXXXX
ABB solar inverters
Technical documentation
Components available for all DC wiring box models -SX / -SY Quantity
Fuse holder
12 or 16
(depending on the type of
wiring box)
Negative string fuses
(-)
22
(
gPV - 1000Vdc - max rating 20A)
12 or 16
(depending on the type of
wiring box)
Components available in the kits supplied with the brackets
Qty (kit
vertical instal-
lation)
Qty (kit
horizontal
installation)
Vertical support assembly
01
bracket.
1 0
