8 - Maintenance
- Error code
- Error message
- Warning
Name of Alarm and Cause Solution
- E006
- Output OC
- Yellow LED
Output overcurrent:
The alarm occurs when the inverter's output current
exceeds the inverter's threshold for maximum output
current.
• Error inside the inverter and cannot be checked externally.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- E007
- IGBT Sat
- Yellow LED
Saturation recorded on the IGBT components:
The alarm appears when one of the active devices of
the inverter is in saturation state.
Once the error appears, the inverter attempts to resume
normal operation.
- Should the error occur sporadically, it may be caused by a
brusque transition of the grid voltage or of the input voltage,
but is not due to a malfunction by the inverter.
- If the error is connected to an internal fault, it will continue to
appear and so it is necessary to contact customer assistance.
- E009
- Internal error
- Yellow LED
Error inside the inverter:
Error inside the inverter
• Error inside the inverter and cannot be checked externally.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- E010
- Bulk Low
- Yellow LED
Low “Bulk” voltage (DC-DC circuit):
The alarm can be caused by causes external to
the inverter: a reduced input voltage on the inverter
(just above the activation voltage) but which is not
accompanied by a sufcient availability of power from
the photovoltaic generator (typical condition of the
stages with limited irradiation)
- If the error signal occurs sporadically, it may be due to
causes external to the inverter (limited irradiation and so
limited power availability from the PV generator).
- If the problem occurs systematically even in conditions of
high irradiation and with input voltage which is signicantly
higher than the activation voltage, contact customer
assistance.
- E011
- Ramp Fail
- Yellow LED
Long wait for “Booster” regime to start:
Error internal to inverter relating to start up time for
DC-DC circuit regime (Booster)
• Error inside the inverter and cannot be checked externally.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- E012
- DcDc Fail
- Yellow LED
Error in the “Booster” circuit (DC-DC side)
recorded by the “Inverter” circuit (DC-AC side):
Error inside the inverter regarding the operation of the
DC-DC circuit part (Booster).
• Error inside the inverter and cannot be checked externally.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- E013
- Wrong Mode
- Yellow LED
Incorrect conguration of inputs (set in parallel
rather than independent):
The alarm is generated solely when the inverter
is congured with parallel inputs. In this particular
conguration the inverter checks the input voltage of
each of the two channels and if the two voltages differ
by more than 20Vdc, the alarm is raised .
• Check that the setting of the "IN MODE" switch is specically
set to "PAR" and that the bridges between the two input
channels have been included.
- If the conguration of the inverter is correct, check that the
input strings have the usual number of standard panels of the
usual brand and with the same inclination/orientation.
- If both the conguration of the inverter and the characteristics
of the PV generator conform with the specications, contact
customer assistance.
- E014
- Over Temp.
- Yellow LED
Excessive temperature inside the inverter:
External temperature over 60°C. This parameter also
depends on the power which the inverter must supply
since the measurement of temperatures is done
internally and is inuenced by the heat dissipated by
the components of the inverter itself
• Check that the inverter is not exposed to direct sunlight. Wait
for the temperatures to which the inverter is exposed to return
to the operating range and for the inverter to cool down.
- If the problem persists (once the ambient temperature has
returned to within the range), contact customer assistance.
You must remember to wait for the time necessary to allow the
inverter to cool down.
- E015
- Bulk Cap Fail
- Yellow LED
Breakdown recorded on the “Bulk” capacitor:
Error inside the inverter regarding a problem in the
bulk capacitors.
• Error inside the inverter and cannot be checked externally.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- E016
- Inverter Fail
- Yellow LED
Error in the “Inverter” circuit (DC-AC side)
recorded by the “Booster” circuit (DC-DC side):
The alarm is generated when a problem is detected in
the inverter circuit part (DC/AC).
• Error inside the inverter and cannot be checked externally.
- If the problem persists (once the inverter has been switched
off and back on again), contact customer assistance.
- E017
- Start Timeout
- Yellow LED
Long wait for “Inverter” regime to start up:
Error internal to inverter relating to start-up time for the
DC-AC circuit regime (Inverter)
The alarm can be caused by causes external to
the inverter: a reduced input voltage on the inverter
(just above the activation voltage) but which is not
accompanied by a sufcient availability of power from
the photovoltaic generator (typical condition of the
stages with limited irradiation)
- If the error signal occurs sporadically, it may be due to
causes external to the inverter (limited irradiation and so
limited power availability from the PV generator).
- If the problem occurs systematically even in conditions of
high irradiation and with input voltage which is signicantly
higher than the activation voltage, contact customer
assistance.
