Case studies
System Manual
142
Unit with three indoor stations:
If further indoor stations are added to a unit, this is a special feature.
These additional indoor stations are separated from the remaining devices and constitute an
independent network. At the end of the installation there is the building network and the units
network (with the additional indoor stations).
For the integration of additional indoor stations there are several situations, see chapter 7.3
“Adding a unit network / indoor stations to a unit“ on page 144.
In this example two additional indoor stations are integrated via a PoE switch.
PEo
PEo
Fig. 127: Overview: Unit with several indoor stations
