Case studies
System Manual
│
141
Unit with door opener:
The entrance door is equipped with a door opener. For this an IP switch actuator is required
which accepts the digital opening command and switches the door opener.
PEo
Fig. 125: Overview: Unit with door opener
PoE
LAN LAN LAN LAN
DC+/-
LAN 1 (PoE)
DC+/- LAN (PoE)
GND DC+ LOCK COM NC NO
LAN (PoE)
GND
DC+
IN
LOCK+ LOCK
LAN (PoE)
Fig. 126: Connection: Unit with door opener
