AccuEnergy AcuRev 1300 User Manual

107
AcuRev 1300
Pulse Output
Isolation voltage 2500Vac
Load Voltage 0-25Vac
Load current 10mA(max)
Power Supply
Working Power Supply 100-415Vac,50/60Hz; 100-300Vdc
Power Consumption <2W or <10VA
Appendix B Technical Specications and Parameters
The transformer connected to the measurement
Parameter Accuracy Resolution Range
Active energy 0.5% 0.1kWh 0-999999.9
Reactive energy 0.5% 0.1kvar 0-999999.9
Apparent energy 0.5% 0.1kVAh 0-999999.9
Voltage 0.5% 0.1V 175.0V-265.0V
Current 0.5% 0.001A 100mA-80A
Active power 0.5% 0.1W -80-80kW
Reactive power 0.5% 0.1var -80-80kvar
Apparent power 0.5% 0.1VA -80-80kVA
Power factor 0.5% 0.001 -1.000-1.000
Frequency 0.2% 0.01Hz 50/60
Power demand 0.5% 0.1W/var/VA 80kW/kvar/KVA
Current demand 0.5% 0.001A 80A
