67
AcuRev 1300
2. Preset/Reset Multi-Register (Function Code 10H)
Set:
Function code 10H allows users to change multiple registers’ content, including
system parameter, time-division energy parameter, initialization energy.
Table 5-6 is an example of It's Total Active Energy is 0.20KWh,Total Active Energy tari
1 is 0.12KWh,Total Active Energy tari 2 is 0.08KWh 17th slave device.
Table 5-6 Preset Energy Data
Addr Fun
Data start
reg HI
Data start
reg LO
Data #of
reg HI
Data #of
reg LO
Byte Count
11H 10H 09H 00H 00H 02H 04H
Value HI Value LO Value HI Value LO CRC HI CRC LO
00H 00H 00H 14H CDH 30H
3.Read the relay output state (functional code 01 h)
Query data frames:
Query data frame, the host to send data from the machine frame.01 function allows
the user to obtain the specified address from the machine5.2 the Modbus protocol
communication application format explanation of relay output state ON/OFF (1 = ON, 0 =
OFF), in addition to from the machine address and functional domains, still need to be in
the data eld contains a data frame will be read by the initial address and number of relay
to read.
Table 5-7 Reading Relay Output State of Querying Data Frames
Addr Fun
Data start
reg HI
Data start
reg LO
Data #of
reg HI
Data #of
reg LO
CRC16
HI
CRC16
LO
11H 01H 00H 00H 00H 02H BFH 5BH
