37
AcuRev 1300
1) Reactive power calculate pattern
Real reactive:
Generally reactive:
2) Energy pulse output
Used to choose the pulse type that represented by the pulse outputted through P1,P2
terminals.
Active: P1,P2 terminals output pulse is active power pulse.
Reactive: the output pulse is reactive power pulse.
3) Demand
Demand supports 4 kinds of calculate methods, which is Sliding block method, xed
block method, rolling block and thermal demand method.
a) Sliding block method: set a 1-30min window time, that is calculate time of demand.
The window slid once per minute, so does the demand value. In this method, in the
operation state demand calculation method is displayed to slip.
b) Fixed block method: set 1-30min as a demand calculate cycle. The whole cycle just
calculate the demand once. Which means the demand update time is equal to the demand
calculate cycle. In this method, in the operation state demand calculation method is
displayed to block.
c) Rolling block method: set 1-30min as a demand calculate cycle and 1 slip time.
Demand cycle must be integrated multiples of slip time. Calculate 1 cycle’s demand at the
end of the slip time. The demand update time is equal to the slip time. In this method, in
the operation state demand calculation method is displayed to slip.
d) Thermal demand method: calculate the demand value through analog the theory
