40
AcuRev 1300
4.2 Basic Measurement Functions
AcuRev 1300 mainly measure the Voltage, Current, Power, Frequency, Power Factor,
demand. Demand supports power demand,current demand and demand prediction
function.Among them, the center line current support calculated value and measured
value of two kinds of algorithms, AcuRev1303 and below model using calculated value;
AcuRev1304 and above model using measurement values, and support the calculation
value of the residual current.
The gure below is the basic measurement parameter display.
Figure 4-2 Basic Measurement Parameter Display
4.3Measurement function
AcuRev 1300 series instrument provide time-sharing two-way total electric energy
metering system and split phase electricity.The departed time could be any day during the
date 1-28. Real – time energy can change the energy base. Communication only can be
changed under the high permission and sealing open condition. Support of electricity data
