52
AcuRev 1300
Delay time: how long will the alarm conditions keep after that event is established.The
setting range of 0 ~ 30000, the per unit time is 1 ms, set to zero without delay, immediately
trigger the alarm events.1/10 of the communication value of the actual value.
Output to the relay: set to 0, alarm occurs, the group is not output from RO.If set to 1,
assuming the M11 module is connected, and M11 RO work mode setting of alarm mode
in the module, alarm occurs, the group output to the RO1, namely RO1 closed, until all the
output to the RO1 alarm RO1 to disconnect after recovery.RO2 ~ RO8 and RO1 principle
is the same.Note: when the relay is used for alarm output only "level" output mode, there
is no "pulse" output mode, the relay output Settings (pulse or level) will be ignored.After
completion of a single event of the functions of setting, the need for the following global,
alarm function can be normal use.
2. The alarm global Settings
The communication address table 700 h to 704 h address global parameters for alarm
correlation.Alarm switch: always determines whether this instrument enable event alarm
function, and is set to "1", to enable the alarm function, related to the alarm Settings to take
eect.
Each alarm channel stop switch: to determine whether the alarm set in each group.As a
16-bit unsigned integer, the bit0 ~ bit11 respectively corresponding to the group 1 to 12
group can set the alarm, the corresponding bit is "1" when the group alarm set to take
eect, otherwise is invalid.
When the alarm events, can be congured RO work mode, make it as an alarm output.
AcuRev1300 support 2 alarm output modes, pulse output mode and the level of output,
respectively, when choosing pulse output mode, you can set the corresponding pulse
width, the range of 50 ~ 3000 ms.And need to congure the various alarm output channel
can make logo, the bit0 ~ bit11 respectively corresponding to the group 1 to 12 groups can
make alarm output, the corresponding bit is "1", the group of alarm events, RO accordingly
output, otherwise is invalid.
