AccuEnergy AcuRev 1300 User Manual

75
AcuRev 1300
212H 530 CT2 Value word R/W 1; 5; 100; 200; 333
According
to the
order
1~4 1
213H 531 CT1 Value word R/W 1~50000/5~50000 5 1~4 1
214H 532 CTN Value word R/W 1~50000/5~50000 5 4 1
215H 533 PT2 Value word R/W
50.0~400.0
(Communication value
is 10 times of the real
value)
220.0 1~4 1
216H-
217H
534-
535
PT1 Value word R/W
50.0~999999.9
(Communication value
is 10 times of the real
value)
220.0 1~4 2
218H 536
Energy Pulse
Constant
word R/W 1-60000 5000 1~4 1
219H 537
Energy Pulse
Width
word R/W 20-100 ms 80 1~4 1
21AH 538
Energy display
Decimal
word R/W 0,1, 2, 3 1 1~4 1
21BH 539
Relay Operating
Mode
word R/W
0: Relay Control
1: Alarm Output 0 2~4 1
21CH 540
connection
detection enable
word R/W 0:No enable 1:Enable 1 1~4 1
Table 5-14 display programming table
Page No. Setting ag Content
Model
1
Model
2
Model
3
Model
4
1 Voltage wiring detection √ √ √ √
2
Current connection
detection
√ √ √ √
3 Instrument address √ √ √ √
4
RS485 communication baud
rate
√ √ √
