51
AcuRev 1300
1.Single event alarm Settings
Table 4 -1 lists the content and address, and the parameters of the first set of set
records recorded a total of 12 groups of such Settings, the format is the same.
The Modbus
address
Parametric
description
Data type Read and write
attribute
Numerical range Register
number
705 Parameter
number
word R/W 0 ~ 28 (see
attachment)
1
706 Compare the
way
word R/W Is greater than 0;
Is equal to
1; Less than 2
1
707 The set value word R/W 1
708 Delay time word R/W 0~3000(×10ms) 1
Table 4-1 First set alarm parameters setting
Alarm parameter number: select the group related parameters, such as 12 - frequency
(refer to chapter 5 in the "serial number corresponding alarm parameters table"),
alarm, the group will judge conditions for this parameter.Comparative way, value: build
alarm conditions, such as greater than, equal to, less than set value.If set frequency, is
greater than, 50, alarm condition for more than 50 hz frequency.Note: the "set point" is
corresponding with the principal part of parameters, it communication value and actual
value of the conversion relations in the following table.
Parameter number Communication value of the set value and the actual value of
multiple relationship
0~3 1000
4~11 10
12 100
13~24 1
25~28 1000
