AcuRev 1300
7)Primary side/secondary side to choose
Electricity and electric parameter data for one side or the secondary side of data
8) Connection mode
According to the actual to select the correct connection mode, otherwise it will lead to the
measurement data is not correct.
9) CT PT set
According to the practical use of set, otherwise, can lead to inaccurate measurement.
10)The pulse constant and pulse width
According to actual use the set, otherwise, can lead to inaccurate pulse output
11)Electricity decimal digits Settings
According to the set, electric energy according to dierent decimal digits, when change
the Settings, may cause the error of electric energy metering.
12)RO output mode
RO output mode can be configured to remote control or alarm output, output can be
congured according to the practical application.
