Rate parameter error information word 1(basic parameter)
Table 5-18 Rate parameter error information word 1
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
1 1 1 1 1 1 1 1
Weekend
seg set error
Holiday set
error
Holiday no.
over
Time zone
set error
Time zone
no. over
Time seg
table no. over
Time seg no.
over
Rate no.
over
Rate parameter error information word 2(time segment table parameter)
Table 5-19 Rate parameter error information word 2
Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
1 1 1 1 1 1 1 1
Time seg
table 8 error
Time seg
table 7 error
Time seg
table 6 error
Time seg
table 5 error
Time seg
table 4 error
Time seg
table 3 error
Time seg
table 2 error
Time seg
table 1 error
Alarm Parameter Setting(Function Code: 03H to Read; 10H to Write)
Table 5-20 Alarm Parameter
Modbus address
Parameter description
Data
type
R/W Data range Default Model
Register
number
HEX Decimal
700H 1792 Alarm Switch word R/W 1: Enable; 0:
Disable
0 2~4 1
701H 1793 Alarm Channel word R/W Bit0~ Bit11:
Alarm Channel
0-11
1: Enable; 0:
Disable
0 2~4 1
702H 1794 Alarm Channel
Output
word R/W Bit0~ Bit11:
Alarm Channel
0-11
1: Enable; 0:
Disable
0 2~4 1
703H 1795 Alarm Output Mode word R/W 0: level; 1: pulse 0 2~4 1
