25
AcuRev 1300
6
Four-quadrant reactive power
display
To indicate the rst to forth quadrant reactive power
7
Import icon on: display the Energy Import
Export icon on: display the Energy Export
8 Load character indicate
Inductance icon on: inductive load
Capacitor icon on: capacitive load
9 unit Unit of the parameter in parameter display area
3.2 Display Mode and Key Operations
The LCD display consists of important parameter display mode, all parameter display
mode and setting mode.
1. Important parameter display mode
The important parameter display area mode mainly display the important parameters,
including system default display data and custom data. Each page display lasts about 6
seconds. When we press “SCROLL” in a short time, the current screen content would be
locked for 1 minute and light up the backlight, during this time, press the same key in the
same way another time, it would turn to the next page and lock the display for 1 minute;
when we didn’t press any key for one minute, then it would display all the pages in a rate of
6 second per page automatically.
System default display content:
A) the input active power (AcuRev1301 ~ AcuRev1304 support)
B) the output active power (AcuRev1302 ~ AcuRev1304 support)
Custom data content: The 11
th
-42
th
screen data could be set to important parameter
display mode, and be cycle displayed. See table 3-2 Display coding table.
Note:
Conguration 1: using the communication way , we could add 1 to the corresponding
