15
AcuRev 1300
AcuRev1300 series instrument connection mode Settings and the corresponding
practical application in engineering and correct, to ensure the measurement accuracy of
instrument.
1). 3LN, 3CT; The connection mode set to 3LN
ABCN
LINE
1A FUSE
I11
I12
I21
I22
I31
I32
I41
I42
V
N
V3 V2 V1
AcuRev 1300
LOAD
Terminal Block
