17
AcuRev 1300
3). 2LL,2CT;The connection mode is set to 2LL; Note: mutual inductance type
secondary side output for 5A/1A,Rogowski coil 333mV,200mA
ABC
LINE
1A FUSE
I11
I12
I21
I22
I31
I32
I41
I42
V
N
V3 V2 V1
AcuRev 1300
LOAD
Terminal Block
