136.0
m/s
2
AC
000/000 RMS
0 Range 200
Battery remaining capacity
AC power adapter connector
Battery installation
The indicator is shown battery remaining capacity on the upper right of a display screen.
The following displays tell you the condition of the batteries.
Full
When LCD display tells low battery, install new batteries.
For long-term measurement, install new batteries in advance.
１－２ AC power adapter
１）Turn off the
Power
switch.
２）Connect the optional AC power adapter to the AC power adapter connector.
３）Put the AC plug in the AC 100V outlet.
！ CAUTION
Do not use the AC power adapter other than the one recommended.
Other type of adapter may cause damage to the instrument.
１－３ Power ON
Long-press the
Power
button for 1 sec or more. Immediately after the power goes on, the
following screen is displayed:
After about 5 seconds
Type3116
Ver. 1.2
2000/01/01
00:00:00
Power
136.0
m/s
2
AC
000/000
RMS
0 Range 200
EMPTY
Replace batteries
To Next Page
