ACO 3116 - Page 47

5
Change the mode
and the value
Select
The command
Measurement value Mode
Measurement Range
Detector characteristics
Display of command
Display of a state
Display of command
Change the mode
and the value
Select
The command
Measurement value Mode
Measurement Range
Display characteristics
Display of a state
Display of command
３－２ Measurement the velocity（VEL）
The current value is displayed in digital form at an interval of 2 sec and a bar at an interval of 0.1
seconds.
000/000 RMS
＜ Change of the measurement mode ＞
１）Select the command with cursor button , the Range change to
Mode
.
２）Mode is
mm/s
with cursor button .
（
m/s
2
→
mm/s
→
μm
→
m/s
2
→
mm/s
）
The operation method of a measurement range and display mode is the same as acceleration
(ACC).
３－３ Measurement the Displacement（DISP）.
The current value is displayed in digital form at an interval of 2 sec and a bar at an interval of 0.1
seconds.
000/000 RMS
Display of command
＜ Change of the measurement mode ＞
１）Select the command with cursor button , the Range change to
Mode.
２）Mode is
μm
with cursor button .
（
m/s
2
→
mm/s
→
μm
→
m/s
2
→
mm/s
）
The operation method of a measurement range and display mode is the same as acceleration
(ACC).
136.0
m/s
2
AC
000/000
RMS
0 Range 200
136.0
m/s
2
AC
000/000
RMS
0 Range 200
