XM_unity_Installation&Maintenance_Manual Ed.1.3c2013 Page '=of (()
Chart B:
*(
The independent power cable connecting the mains of the XMIND unity light must be twopole type of section ≥1,5mm
2
(16
AWG) and complying to standards CSA/UL IEC.
The signal cable connecting the timer and the XMIND unity light for external use must be twopole type of section ≥0,5mm
2
(20
AWG) and complying to standards CSA/UL IEC.
The cable connecting the timer and the XMIND unity remote exposure switch for external use must be threepole type, of section
≥0,3mm
2
(24 AWG) and complying to standards CSA/UL IEC.
The electric line characteristics must (Chart C)
Chart C:
To Next Page
