The USB cable of the USB repeater can be routed out from the bottom side of the xray control unit (as shown previously) or routed
in the back of the wall plate, for the routing inside the wall plate, follow the same instructions specified for routing the PWR cables
and COMM. cables of the bracket (which are exiting from the scissor arm)
