Page 5Bof (()XM_unity_Installation&Maintenance_Manual Ed.1.3c2013
**)*"
ASSEMBLY INSTRUCTIONS (Fig. 5.45.6)
1. Remove the XRay Control Unit (timer) plus wall plate plus drilling template assembly from the packaging.
2. Start to disassemble the wall plate from the timer unscrewing the four screws D=E on the front cover and lift it to
remove the cover D;E4
3. Then unscrews the four screws D5E of Control power board box D'E4
4. At this point the wall plate and timer back cover D(Ecan be installed to the wall.
