Doc : AM220-001E Release: 1.5 updated : October 2014
Principle of the SP 10 apparatus
The SP 10 uses a patented system (License TOTAL RM) based on a video camera that observes the flame
and an actuator that adjusts the size of the flame. The flame image is digitalized and the dedicated
software analyses the shape of the flame during the test. When the flame shape corresponds to the one
described in the test method, the SP 10 memorizes the height of the flame. This specific flame is the one
with the maximum height without generating smoke. After three consecutive readings, the instrument
reports the average value corrected with the lamp factor according to the standard.
Internally ; 100,000 results
Externally : Limited only to capacity of external device
Serial port (printer is optional)
W x D x H
330 x 390 x 413 (13”x 15”x 16”)
115 to 230V - 2 A - 50/60 Hz
