SP 10 ANALYZER DESCRIPTION
SP 10 instrument description:
1 – Full color display with touch screen
2 – Test lamp compartment
3 – Candle
4 – Candle conveyor
5 – USB port on front panel
6 – RJ45 Ethernet socket
7 – USB port on rear panel
8 – RS232 port
9 – Main switch and main power socket
10 – Cooling fan
Front view
Rear view
1
2
3
4
1
0
9
5
7
7
8
6
7
