position, pin 1 of the balanced outputs is connected to circuit
ground. In the LIFT position, pin 1 of the balanced outputs is
disconnected from circuit ground.
MIDI Connectors
[10] Phantom Power Input which accepts AC power adapters for ADA MIDI
footswitches and connects to pins 6 and 7 of the MP-2's MIDI
In jack. When used in conjunction with the proper 7-pin DIN
phantom power cable, allows ADA MIDI footswitches to be
remotely powered.
[11] MIDI In When connected with a standard MIDI cable, receives data
from a MIDI controller. By plugging an ADA AC power adapter
to the Phantom Power jack and using a 7-pin DIN phantom
power cable from this jack to an ADA MIDI footswitch, power is
supplied from this jack to the controller through the MIDI cable.
[12] MIDI Out Carries MIDI data output by the MP-2.
[13] MIDI Thru Carries an exact copy of data received at MIDI In.
[14] AC power cord Plugs into a normal wall outlet.
[15] Fuse Accepts a .5 A (for 117V US models) or .25 A (for 230V export
models) Slo-Blo type fuse.
[16] Power Switch Switches MP-2 on and off.
