Appendix A
Specifications
Inputs (Front and Rear)
Connectors: Unbalanced (TS) 1/4" phone. Front panel jack overrides rear
panel jack.
Maximum Input Level: +12.2 dBV (3.4V RMS)
Input Impedance: 390 kilohms
Stage Outputs
Connectors: Unbalanced (TS) 1/4" phone
Maximum Output Level: +11.1 dBV (3.6V RMS) into 600 ohms
+ 17.1 dBV (7.2V RMS) into 50 kilohms
Output Impedance: 500 ohms
Recording Outputs
Frequency Response: Bandwidth limited to approximately 50 Hz-3 kHz
Connectors: Balanced 3-pin XLR (pin 3 hot) Unbalanced (TS) 1/4" phone
Maximum Output Level:
Unbalanced: +11.1 dBV (3.6V RMS) into 600 ohms
+17.1 dBV (7.2V RMS) into 50 kilohms
Balanced (Line): +12 dBV (4V RMS) into 600 ohms
Balanced (Mic): -16 dBV (.15V RMS) into 200 ohms
Output Impedance: 500 ohms
Effects Loops Sends
Connectors: Unbalanced (TS) 1/4" phone
Maximum Output Level:
Line: +11.1 dBV (3.6V RMS) into 600 ohms
+17.1 dBV (7.2V RMS) into 50 kilohms
Instrument: -8.9 dBV (.36V RMS) into 600 ohms
-2.9 dBV (.72V RMS) into 50 kilohms
Effects Loop Returns
Connectors: Unbalanced (TS) 1/4" phone
Maximum Input Level:
Line: +20 dBV (10V RMS)
Instrument: 0 dBV (1V RMS)
Input Impedance: 10 kilohms
Power Consumption: 35 watts
Size: 1.75" Hx 19"Wx9.5"D
Weight: 7 Ibs.
Page: 53
