4-14 ADS TRITON+ Manual
The Description field indicates the physical description for the
monitoring point based on the selected pipe/installation type,
dimensions, and other characteristics (when applicable).
3. (optional) Click on the Display button to show a simple
illustration of the pipe based on the current parameters.
4. Assign the appropriate devices to the monitoring point, and
edit each device as necessary. Refer to Assigning and Editing
Devices on page 4-15 for more information and instructions.
5. Enter or edit the current location’s USGS latitude and
longitude coordinates in the Latitude and Longitude fields.
6. Select the combo sensor containing the depth sensor you want
to use for the UNIDEPTH entity from the Depth drop-down
list. ADS recommends using the default of AUTO.
7. Select the combo sensor containing the velocity sensor you
want to use for VELOCITY entity from the Velocity drop-
down list. ADS recommends using the default of AUTO.
8. Enter the depth of the silt at the bottom of the pipe at the
monitoring point in the Silt field.
9. Enter the Hydraulic Coefficient in the HC to be used in the
Manning equation, as appropriate.
10. (applies only to a second monitoring point) Click on the
Monitoring Point 2 tab, and repeat steps 1 through 7.
11. Click on the Save button to store the new information and
changes to your local directory or network.
Note: Once you have finished entering and/or editing the
monitor and monitoring point, you must activate (or
reactivate) the monitor.
