4-38 ADS TRITON+
®
Manual
Edit the following parameters corresponding to the temperature
sensor in the AV|Gated sensor:
z Sensor Select the source from which to measure the
temperature used when compensating for temperature in Peak
Combo Sensor readings. The channels correspond to the
sensors connected to those channels (ports) on the monitor.
The option selected here should be consistent with the option
selected for the Channel in the Device Parameters section at
the bottom of the dialog.
Note: The stored temperature value is the actual water
temperature reading from the AV|Gated sensor.
z Store Data Select this checkbox to ensure the monitor logs
the temperature data to memory. This option is selected by
default.
