Gathering Parts and Supplies
Obtain the following supplies before installing the ring and sensors
to prevent any costly delays. When ordering, specify the
TRITON+ flow monitor installation hardware for ring mounting.
In addition, please indicate the type of mounting hardware desired
for mounting the monitor: mounting bracket (wall/rim mount) or
hook (rung mount).
Quantity
Description
ADS P/N
1
TRITON+
flow monitor (
battery or externally-
powered)
8000-FST-IM-
4WW
-XXX
, 8000-
FST
-IM-EP-
4WW-
XXX
1
Monitor mounting bracket/flange (for mounting
monitor to manhole rim or wall)
I40–0009
3
Monitor mounting bracket bolt, hex, SS, M8 x
30mm
508058
3
Monitor mounting bracket washer, flat, SS
517-8001254-00
3
Monitor mounting bracket washer, split lock, SS
517-8001274-00
1 as
needed
Hook, SS, 2-piece w/ hardware
(for hanging monitor on manhole rung;
Alternative to ADS p/n I40-0009)
8000-0021
1 as
needed
Bracket, mounting, sliding, for
ParaDepth,
ParaFlow, Surface Combo or Ultrasonic Depth
Sensors (mounting plate)
8000-0307-02
1 as
needed
KIT, SYSTEM, MOUNTING BRACKETS,TOP-
SIDE (includes Mounting Hardware Kit)
8000-0655-A
1 as
needed
Tool, Retrieval, Extendable, 4-Section,
Aluminum (part of th
e Topside Retrieval
System for ParaDepth and ParaFlow Sensors)
8000-0654
1 as
needed
Adapter, Silt Mount for AV|Gated, AV|Max or
Peak Combo Sensors
8000-0271
1
Stainless steel ring (sized for pipe)
I25-0081 to 0094
See Appendix B
Up to 2
(1 per
monitoring
point)
AV|Gated Sensor – upward ultrasonic depth
sensor, surcharge pressure depth sensor,
gated velocity sensor and water temperature
sensor
8K-CS7-10-35
(35-ft./10.6-
m or
100-ft./30.5-
m
cable)
