ADS TRITON+ - Page 215

Sensor Installation and Connection 5-9
Quantity
Description
ADS P/N
Up to 2
(1 per
monitoring
point)
AV|Max Sensor –
upward ultrasonic depth,
sensor, press
ure depth sensor, peak velocity
sensor, and water temperature sensor
8K-CS9-10-
35
(35-ft./10.6-
m or
100-ft./30.5-
m
cable)
1 as
needed
Inclinometer -
Angle/Tilt sensor installed on
flood gates or other components where angle
of change is needed
8000-0528
1 as
needed
Long Range Depth Sensor – downward
ultrasonic depth sensor typically installed near
top of manhole structure
8K-CS6-C1-
10
(10
-ft/3.05-m c
able)
Up to 2
(1 per
monitoring
point)
ParaDepth Sensor –
downward ultrasonic
depth sensor and air temperature sensor
8K
-CS8-D1-00-
30-
IS
(30
-ft/9.1-
m or 100-
ft/30.5-
m cable)
Up to 2
(1 per
monitoring
point)
ParaFlow Sensor
–
downward ultrasonic depth
sensor, surcharge pressure depth sensor,
surface velocity sensor, surcharge velocity
sensor and air temperature sensor
8K
-CS8-V2-10-
30-
IS
(30
-ft/9.1-
m or 100-
ft/30.5-
m cable)
Up to 2 (1
per
monitoring
point)
Peak Combo Sensor
– upward
ultrasonic depth
sensor, pressure depth sensor, p
eak velocity
sensor and water temperature sensor
8K-CS4-xx-35
/1H
(35-ft./10.6-
m or
100-ft./30.5-
m
cable)
2
Up to 2
(1 per
monitoring
point)
Surface Combo Sensor
–
downward ultrasonic
depth sensor, surcha
rge pressure depth
sensor, surface velocity sensor, surcharge
peak velocity sensor, and air temperature
sensor
8K-CS5–V2-
xx-
30/1H
(30-ft./9.1
-m
or 100-ft./30.5-
m
cable)
2
Up to 2
(1 per
monitoring
point)
Ultrasonic depth sensor (
downward
ultrasonic
depth only)
8K-CS5-D1-00-30
(30
-ft/9.1-
m or 100-
ft/30.5-
m cable)
1 as
needed
IS standard or custom sensor extension cable
for Ultrasonic Depth Sensor
8000-0023–xxx
3
1 as
needed
IS Standard or Custom Sensor Extension
Cable
for Peak Combo and Surface Combo
Sensors
8000-0025–xxx
3
as needed
¼
- u 2 ¼-
in. stainless steel anchor bolts w/ nut
and washer
1
3/8-inch x 3-inch stainless steel anchor bolt and
