5-24 ADS TRITON+ Manual
Mounting the AV|Gated, AV|Max or Peak
Combo Sensors
Important: If the only sensor to be installed on the ring
is a single AV|Gated, AV|Max or Peak Combo, the sensor
should be at the 6:00 position and the crank should be
rotated left or right to the 10:00 or 2:00 position so as not
to interfere with the Upward Ultrasonic reading during
surcharge conditions.
Mount the AV|Gated Sensor, the AV|Max Sensor or the Peak
Combo Sensor to the ring in the following way:
1. Use two M3 X 10mm stainless steel flathead screws (do not
substitute any other screws) to attach the sensor at the bottom
of the ring (opposite from the ParaDepth, ParaFlow or Surface
Combo Sensor/Ultrasonic Depth Sensor).
□ ADS recommends installing AV|Gated, AV|Max and the
Peak Combo sensors within 5 degrees of the pipe
centerline.
Important: If the AV|Gated, AV|Max or Peak Combo
will be installed in pipes with very fast velocities or have
potential for debris impact (a Combined Sewer Overflow),
install the sensor with the blunt end facing downstream,
preferably in the output pipe.
□ The AV|Gated sensor must be installed within +/- 5
degrees from the bottom center of the pipe.
