6-16 ADS TRITON+ Manual
Feeding AC power cable through XIO/XBUS cable gland
Note: When positioning the cable inside the XIO, XBUS,
or other enclosure, maintain a small space between the
cable and the right side of the ExPAC.
6. Loosen the screws on the AC input terminals at the bottom,
front of the power supply.
XIO/XBUS
AC POWER CABLE
CABLE GLAND
To Next Page
