11-12 ADS TRITON+ Manual
Note: Move the monitor away from the hazardous area
before opening the monitor to replace the battery.
Warning: The TRITON+ can receive internal power
only from the ADS 12-volt IS battery pack (p/n 8000-
0043-02/04). Do not use any other battery or power
source to power the monitor internally.
ADS offers a replacement 12-volt battery pack (ADS p/n 8000-
0043-02) to replace the existing battery pack when the battery
voltage is low or falls below the previously specified level.
Replacing the 12-volt battery pack involves a relatively simple
process.
Note: Battery pack replacement involves removing the
existing PCB for reuse with the replacement battery pack.
Therefore, do not discard or replace the PCB unless it is
necessary.
12-volt battery pack with PCB
Replace the internal battery in the TRITON+ monitor in the
following way:
