Specifications A-9
Pressure
Resolution
0.01 inches (0.25 mm)
Long Range Depth Sensor (ADS p/n 8K-CS6-C1-10)
This sensor supports downward ultrasonic depth at long range and
detects surcharge levels near the manhole lid.
Long Range Depth
Housing
ABS plastic shell, polyurethane-filled
Dimensions
9.15 inches (232.4 mm) long x 4.40 inches (111.8
mm) wide x 4.22 inches (107.2 mm) high
Cable
Standard size: 10.0 feet (3.05 m) long x 0.285
inches (7.2 mm) nominal OD, polyurethane jacket
Extension cables available up to 300 feet (91 m)
Operating /
Storage
Temperature
Operating: -4° to 140° F (-20° to 60° C)
Storage:
-4° to 167° F (-20° to 75° C)
Note:
The sensor will not produce accurate
readings when ice is built up on the sensor.
Accuracy
0.25% of range or 0.13 inches (3.2mm) whichever
is greater in a constant temperature air column
Deadband
0.00 inches/mm
Frequency
75kHz
Range
240 inches (6.1 m) from bottom of sensor housing
Resolution
0.01 inches (0.25 mm)
Drift
0.0 inches/mm
Submersion Sensor
Housing
ABS plastic shell, epoxy-filled
Dimensions
2 inches (50.8
mm) length x 2 inches (50.8
mm)
wide x 1.14 inches (29 mm) high
Cable
3 ft. (0.91 m) length, 0.35 inches nominal (8.9mm
nominal) OD, polyurethane jacket.
