61287722G1-5B 1

Total Access 372

Small Business Unit ONT

Scope of this Guide

ThisdocumentprovidesinstructionsfortheinstallationandmaintenanceoftheTotalAccess

372SmallBusinessUnitONT(SBUONT).Itincludesinstallationinstructions,LEDdescrip‐

tions,regulatoryinformationandtroubleshootingprocedures.

In this Guide

ThisguidecontainsthetopicslistedinTable1.

Table 1. Topic List

Topic See Page

Description 2

SafetyandRegulatoryCompliance 4

ComponentsandInterfaces 6

Installation 12

MountingtheElectronicsModuleIndoors 30

Troubleshooting 35

Maintenance 42

Specifications 42
