ADTRAN Total Access 372 - Outer Enclosure Security Locking Feature

Components and Interfaces
61287722G1-5B 7
Outer Enclosure with Cover Removed
TheOuterEnclosurebase(refertoFigure1)containscableentrypointsforpower,ground,
Telcoincomingcablingandcablingtothecustomerpremesis.Eachcableentryhasgrommets
toprovideenvironmentalprotection.ThecableentriesalsosupportstrainreliefwithTie‐
wraps.
Figure 1. Enclosure and Electronics Module
NOTE
Inthefigureabove,thecoverfortheEnclosurehasbeenremovedforclarity
purposes.
Telco Access Screw
Surface Mounting
Hole
Surface
Mounting
Hole
TELEPHONE TROUBLESHOOTING:
1. Identify the bad line (POTS 1-8).
2. Plug any working phone into
the appropriate jack.
If the telephone works, the unit
is functioning normally.
If the telephone does not work,
contact your service provider.
3. Remove the telephone from the
POTS jack.
TOTAL ACCESS 372
1287722G1
