Mounting the Enclosure Outdoors
NOTE
Wheninstalled outdoors,anAdtranModel774or775seriesNIDhousing
mustbeused.
Useamaximumofa#10screwtofitproperlyinthediameterofthemountingholes(see
Figure5).Makesuretoleaveaminimumclearanceof2inches(5.1cm)fromthehingesfor
openingthedoor.Completethefollowingstepstomounttheenclosure:
1. Chooseaverticalsurfacenearanap
provedground,butawayfromdownspouts,perma‐
nentwatersprinklers,orotherwatersources.
2. Usethetopandbottomsurfacemountingholesandacarpenter’sleveltomarkthe
locationsforthethreemountingbracketsonthemountingsurface.
3. Pre‐drillthemarkedlocationsandinstallaminimumof1/
4inch
diameterlagbolts,with
aminimumlengthof3inchesthatareappropriatetosecuretowallstuds.
4. MounttheSBUONTtothesu bscriberpremises.
NOTE
Considerationshouldbegiventoallowproperclearanceforopeningthe
ONTdoor.
Figure 5. Enclosure Mounting Holes
Surface Mounting
Bracket
Surface Mounting
Bracket
Surface Mounting
Bracket
