Total Access 372 Small Business Unit ONT Installation and Maintenance Guide
36 61287722G1-5B
LEDs in Fault State
DescriptionsofeachLEDarelistedinTable 9onpage 33withpossiblecausesforfaultLED
conditions.Aflowchartfortroubleshootingtheproblemforeachfaultconditionisprovided
inFigure18onpage37.
SBU ONT Trouble Isolation
ThissectiondescribeshowtoisolateproblemsbasedonfaultsreportedthroughLEDs:
“UPSPowerLEDs”
“NETStatusLEDOffonpage 37
“POTSTroubleshooting”onpage 38
UPS Power LEDs
AUPSPowerLEDthatisoffindicatesthereisnopower.RefertoTable10todetermineifa
problemexists.
Table 10. Power LEDs
Label LED Status Description
AC
z
z
Green
Yellow
UPSisonAC
UPSisonBattery
Output
{
z
Off
Green
Nopower
UPSisprovidingDCtoSBUONT
Battery
{
z
Off
Red
BatteryisOK
Batteryisnotconnectedorisbad
