Installation
61287722G1-5B 25
CAUTION
!
ConnectingtheUPSincorrectlycancauseda magetothe unit.Usecaution
whenconnectingthewiring.
9. PlugtheUPSpowercordintotheutilitypowercordinletontheUPS.
10. PlugtheUPSpowercordintothewalloutlet.(TheUPSbatterycharges whenitis
connectedtotheutilitypower.Thebatterychargesfullyduringthefirst18hoursof
normaloperation.Dono
texpectfu
llbatteryruncapabilityduringthisinitialcharge
period.)
11. Verifyindicatorlightsareinagreementwithmanufacturerspecificationsandtheunitis
functioning.
Table 5. UPS Pin-Out Connection
Pin-Out
Power/Alarm
Description
Pin-Out
UPS
1LOWBAT 1
2BATMIS 2
3REPBAT 3
4ONBAT 4
5SIGRTN 5
612VRTN 6
7 +12VDC 7
