Total Access 372 Small Business Unit ONT Installation and Maintenance Guide

34 61287722G1-5B

Test for POTS Line Faults

Lookatthe“TELEPHONETROUBLESHOOTING”instructionsonthefrontofthe Electronics

Modulefordirectionsindetermininglinefaults.

NOTE

Iftheproblemisstillnotcorrected,itispossiblethereisaninternalwiring

problemwiththepremises.

Provision Ethernet Interface at OLT

EnsureProvisioningoftheSBUONTattheOLThasbeencompleted.Fortheprovisioned

Ethernetlink,useexternalequipment(forexample,alaptopcomputer)toverifytheEthernet

linkisactive.
