Advanced Energy FC-77 Series User Manual

5700512-C I/O Connections and Communication 4-7
Series FC-77X / 77XX, Series FC-78X / 78XX, and Series FC-79X MFCs
SPECIAL FUNCTION SIGNAL DESCRIPTIONS
The following sections provide detailed signal information for signals that are
dedicated to specific functions.
Alarm Output (Error Detection) Signals
Not all MFC models provide these signals. To see if your model provides alarm output
signals see the specifications for the MFC model in question (see “Model
Specifications” on page 6-1). For signal descriptions, see Chapter 4, “I/O Connections
and Communication.”
FC-77X and FC-77XX MFCs provide error detection as a standard feature. The
function is an option on some other models.
For MFCs with the error detection feature, the MFC provides alarm output if it detects
a difference between the flow rate set point and the actual flow rate for longer than
eight seconds.
8 SIGNAL
COMMON
See pin 7.
9 VALVE
TEST POINT
Test point signal indicating the position of the
control valve:
• Open = -13 VDC
•Closed = 0 VDC
Table 4-2. 9-pin connector signal descriptions
Pin Signal
Name
Signal Description
