Specifications
Specification
Imperial
Capacity
*Lifting Capacity CL, XT, BT
7,000 lbs.
*Lifting Capacity WB/BB, WF
8,000 lbs.
Max Capacity / Front Axel
50% of Lifting Capacity.
Max Capacity / Rear Axel
50% of Lifting Capacity.
Height
Leg Height CL
80.375 in.
Leg Height XT, WB/BB, WF, BT
102.375 in.
Top Lock Clearance CL
63 in.
Top Lock Clearance XT, WB/BB, WF, BT
82 in.
Width
Track Width CL, XT, WF, BT
19.25 in.
Track Width WB/BB
23.25 in.
Overall Width CL, XT
108.0 in
Overall Width WB/BB, WF
124.0 in
Overall Width BT
139.0 in.
Width Between Tracks CL, XT, WB/BB, WF
34.5 in.
Width Between Tracks BT
67.75 in.
Width Between Columns CL, XT
92.313 in.
Width Between Columns WB/BB, WF
108.313 in.
Width Between Columns BT
123.00 in.
Width Between Cables CL, XT
88.6 in.
Width Between Cables WB/BB, WF
104.6 in.
Width Between Cables BT
119.3 in.
Length
Track Length CL, XT
155.5 in.
Track Length WB/BB, WF, BT
195.75 in.
Overall Length CL, XT
168.0 in.
Overall Length WB/BB, WF, BT
208.0 in.
Locks
Locking Positions CL
10
Locking Positions XT, WB/BB, WF, BT
14
Lock Spacing CL
5.75 in.
Lock Spacing XT, WB/BB, WF, BT
5 in
General
Wheelbase
115 in.
Vehicle Ground Clearance
5.3 in.
**Standard Motor
120V 20-amp
Rise Time (120v) CL
124 up/ 106 down (seconds)
Rise Time (120v) XT
160 up/ 170 down (seconds)
Rise Time (120v) WB/BB, WF, BT
160 up/ 135 down (seconds)
s
Power Unit Operating Pressure (Max)
2150 PSI
**Optional 240v power unit is available
* Lifting capacity decreases by 25% for wheelbases shorter than 115 inches for each 15-inch increment.
With a minimum wheelbase of 70-inches having a lifting capacity of 75% less or 2,500 lbs. This is due to the
wheels moving closer to the center of the runway where there is less support.
This lift and ramps are designed around a 5.3-inch ground clearance. Longer, shallower ramps may be
needed for vehicles with less clearance.
Please refer to the user manual found in the Power Unit to review the duty cycle. Operating the Power Unit
outside the manufacturer’s specifications will void the Power Unit warranty.
