16 / 94 DLT-V72 Series Manual V2.00 Advantech-DLoG
Right on DLT-V7210K:
Key Explanation
Up to
Special keys S1 up to S12
For customer-specific configuration.
Configure with „DLoG Config“, „ADLoG Linux“ or „ADLoG Android“ (depends on OS).
LEDs
LED
Explanation
LED on: Display of
available internal supply
voltage
Display of excessive or
insufficient temperature in
the device; Temp LED
flashes red
LED on: Indicates access to the
flash drive
