72 / 94 DLT-V72 Series Manual V2.00 Advantech-DLoG
12.3. Integrated low profile Wi-Fi antenna (optional)
Fig. 12.3: Integrated low profile Wi-Fi antenna (optional)
Technical data
Application Wi-Fi IEEE 802.11 a/b/g/n Dual Band Diversity
Number of antennas 2
Type Omnidirectional antenna
Directionality Optimized for the DLT-V72 housing
Frequency range Band 1: 2400 to 2485 MHz
Band 2: 5150 to 5875 MHz
Antenna gain Max. 5 dBi (without loss through the cable)
Impedance 50 Ω
Polarization Vertical/Horizontal
Maximum transmitting power 100 mW / 20 dBm
